Rubber coated systems

Magnet assembly of NdFeB, rubber coat black, with internal thread

PRODUCT INFORMATION:
These systems are used especially on delicate surfaces. Due to the rubber coating occur neither scratches nor discoloration. Moreover the slip resistance is improved thanks to rubber coating.

Alternative to the standard we also offer individual solutions:
» Other colours rubber coating
» Rubber coating harder or softer
» Printable rubber coat

Data sheet
Product variants
Article numberD mmH mmThread MAdhesive force* NShear force* NWeight gTemperature °CSurface
A12D-KsM3NEU12 7 M31163.560schwarz Download CAD file
Rubberised magnet with internal thread 12mm M3 | © Brugger GmbH
Article number: A12D-KsM3NEU
D mm: 12
H mm: 7
Thread M: M3
Adhesive force* N: 11
Shear force* N: 6
Weight g: 3.5
Temperature °C: 60
Surface: schwarz
A18D-KsM4NEU18 6 M4258660schwarz Download CAD file
Rubberised magnet with internal thread 18mm M4 | © Brugger GmbH
Article number: A18D-KsM4NEU
D mm: 18
H mm: 6
Thread M: M4
Adhesive force* N: 25
Shear force* N: 8
Weight g: 6
Temperature °C: 60
Surface: schwarz
A22D-KsM422 6 M43815960schwarz Download CAD file
Rubberised magnet with internal thread 22mm M4 | © Brugger GmbH
Article number: A22D-KsM4
D mm: 22
H mm: 6
Thread M: M4
Adhesive force* N: 38
Shear force* N: 15
Weight g: 9
Temperature °C: 60
Surface: schwarz
A31D-KsM5 ¹ NEU31 6 M589252160schwarz Download CAD file
Rubberised magnet with internal thread 31mm M5 | © Brugger GmbH
Article number: A31D-KsM5 ¹ NEU
D mm: 31
H mm: 6
Thread M: M5
Adhesive force* N: 89
Shear force* N: 25
Weight g: 21
Temperature °C: 60
Surface: schwarz
AS031NdD-05s-03NEU31 6 M589352260schwarz Download CAD file
Rubberised magnet with internal thread | © Brugger GmbH
Article number: AS031NdD-05s-03NEU
D mm: 31
H mm: 6
Thread M: M5
Adhesive force* N: 89
Shear force* N: 35
Weight g: 22
Temperature °C: 60
Surface: schwarz
A43D-KsM4NEU43 6 M4100382960schwarz Download CAD file
Rubberised magnet with internal thread 43mm M4 | © Brugger GmbH
Article number: A43D-KsM4NEU
D mm: 43
H mm: 6
Thread M: M4
Adhesive force* N: 100
Shear force* N: 38
Weight g: 29
Temperature °C: 60
Surface: schwarz
A57D-KsM5NEU57 7,6 M5200787980schwarz Download CAD file
Rubberised magnet with internal thread 57mm M5 | © Brugger GmbH
Article number: A57D-KsM5NEU
D mm: 57
H mm: 7,6
Thread M: M5
Adhesive force* N: 200
Shear force* N: 78
Weight g: 79
Temperature °C: 80
Surface: schwarz
A66D-KsM6NEU66 8,5 M62508510080schwarz Download CAD file
Rubberised magnet with internal thread 66mm M6 | © Brugger GmbH
Article number: A66D-KsM6NEU
D mm: 66
H mm: 8,5
Thread M: M6
Adhesive force* N: 250
Shear force* N: 85
Weight g: 100
Temperature °C: 80
Surface: schwarz
A88D-KsM6NEU88 8,5 M655014018680schwarz Download CAD file
Rubberised magnet with internal thread 88mm M6 | © Brugger GmbH
Article number: A88D-KsM6NEU
D mm: 88
H mm: 8,5
Thread M: M6
Adhesive force* N: 550
Shear force* N: 140
Weight g: 186
Temperature °C: 80
Surface: schwarz
* The forces have been determined at room temperature on a polished plate made of steel (S235JR according to DIN 10 025) with a thickness of 10 mm (1kg~10N). A deviation of up to -10% from the specified value is possible in exceptional cases. In general, the value is exceeded. The type of application (installation situation, temperatures, counter anchors, etc.) sometimes influence the forces enormously. The values given are for orientation purposes. Let our experts advise you.
